DriPak 2000 Filter
Designed for high performance in demanding operating conditions, the DriPak 2000 extended surface pocket filters can function as either prefilters or final filters, where clean air is a necessity.
DriPak 2000 filters are ideal for healthcare facilities, automotive paint booths, commercial buildings, and a variety of industrial applications. Designed and manufactured by AAF Flanders, pioneers in extended surface pocket filters, the ultrasonically-welded DriPak 2000 filter raises the industry standard for value and performance.
Now Better Than Ever
Today’s DriPak 2000 filter features a unique, ultrasonically-welded pocket configuration that guarantees complete pocket inflation and eliminates crowding or leakage. Reinforced pocket support frames eliminate flexing or buckling, even in a turbulent operating environment.
The DriPak 2000 filter is available in four efficiencies, MERV 15, MERV 14, and MERV 12 to meet the requirements of your HVAC system. The DriPak 2000 filter with antimicrobial is designed specifically to improve Indoor Air Quality (IAQ).
Air filters trap and concentrate particulate air contaminants, including viable fungal and bacterial spores. The presence of the antimicrobial preservative in the filter media is intended to preserve the integrity of the media throughout the useful life of the filter. Antimicrobial preservatives are not meant to increase the efficiency of the filter, nor to kill microorganisms “on the fly” as they pass through a filter.
IAQ Engineered
The DriPak 2000 filter is made from layered, meltblown synthetic media, protected by a scrim on the air-leaving side. Layering the media provides both a high-efficiency final filter layer that effectively filters fine particulate, and an integral lofted prefilter layer that captures larger particulate. Meltblown synthetic media is stronger than fiberglass, and is both non-shedding and water-resistant.
Designed for Performance
DriPak 2000 filters employ a sturdy pocket design that includes ultrasonic welding to ensure leak-free pockets. Interlocked support frames attached to the pockets prevent flexing and buckling during full inflation. The double U-shaped, reinforced header forms a solid container for the pocket support frames.
Ultrasonically-Welded Pocket Construction
The DriPak 2000 filter ultrasonically-welded pocket construction features ribbons of fabric sealed inside the pockets to create aerodynamic channels. This eliminates the needle holes associated with span stitching. The contoured shape of the pocket allows full inflation without crowding or restricting airflow, to ensure full media utilization and long service life.
EN779 | M5 – F9 |
ASHRAE 52.2 | MERV 10 – 15 |
ISO 16890 | ePM10 70% – 85% |
Filter Depth (mm) | 305 – 914 |
Media Type | Synthetic |
Frame Material | Galvanised Steel |
Special Size Available | Yes |
Antimicrobial Available | Optional |
Single Header | Yes |
Recomm. Final Resistance | 450 Pa |
Single Header | Yes |
Max. Operating Temperature | 66˚C |
Air Filtration Certificate | UL 900 |
