MEGApleat M13/SC
- Excellent as a secondary filter
- Low operational resistance reduces energy consumption
- Highest dust holding capacity
- The most durable frame construction
- Guaranteed consistent performance
- Patent-pending filter design
- Heavy-duty, galvanised expanded metal support grid
- Also available is the most cost-effective variant
INDUSTRIES
Typical applications
Commercial Buildings
Data Centres
Food and Beverage
Healthcare
Hospitality
Microelectronics
Pharmaceutical
Schools and Universities
The MEGApleat 13 filter’s synthetic, electrostatically charged media has a high initial efficiency and is particularly effective in capturing finer particulate.
The media pack is bonded to a unitized, die-cut box frame at all points of contact, preventing dirty air bypass and promoting even airflow. The MEGApleat 13 filter also has a heavy-duty, expanded metal support grid to increase rigidity and help maintain proper pleat spacing. This ensures maximum efficiency, low resistance, and maximizes dust holding capacity with no racking or vibration of the pleats under normal airflow.
The MEGApleat 13 filter will work in any application where an extended surface pleated panel filter is currently in service, either as a final filter or prefilter. It is particularly suited to applications where high initial efficiency and lower initial resistance are important.
| EN779 | F7 |
| ASHRAE 52.2 | MERV 13 |
| ISO 16890 | ePM10 70% |
| Filter Depth (mm) | 22, 44, 95 |
| Media Type | Synthetic |
| Frame Material | Moisture Resistant Beverage Board |
| Special Size Available | Yes |
| Antimicrobial Available | Optional |
| Recomm. Final Resistance | 250 Pa |
| Max. Operating Temperature | 93˚C |
| Air Filtration Certificate | UL 900 |
