AAF > Products > High Temp Filters > VariCel II HT

VariCel II HT

  • Mini Pleat with ribbon separator
  • Panel filter with aluminium extrusion frame
  • Silicon free construction
  • Maximum operating temperature of 385°C
Category:
Share this:
Description
INDUSTRIES

Typical applications

Automotive
Industrial

Benefits & Features

Construction

The VariCel II HT filter is a high temperature compact air filter, designed for use in automotive drying tunnel installations. This filter features a mini-pleated media pack housed in a sturdy extruded aluminum profile, protected by faceguards on the air entering and air leaving sides. This filter also has a one piece glass rope gasket located on one side. No silicon based adhesives, sealants or glues are used that could degrade at high temperatures and affect the curing process.

Specifications

EN779 M6 – F8
ASHRAE 52.2 MERV 11-14
Filter Depth (mm) 55,78
Media Type Fibreglass
Frame Material Aluminium
Separator Style HT Proseal Tech
Gasket Material Glass Rope
Special Size Available Yes
Antimicrobial Available No
Header Type None Header
Recommended Final Resistance 450 Pa
Max Operating Temperature 385º C
Download Brochure

or
Enquire Now
