AAF > Products > Housing & Equipment > Cleanroom Module > AstroHood S-II
AstroHood S-II - Image 1

AstroHood S-II

  • Room side replaceable filter access
  • Leak free housing with fully welded corners
  • Easy access for filter testing
  • Available with microglass HEPA or ULPA media or extremely durable, low pressure drop eFRM
  • Aerosol injection and upstream port for in-situ test are available
Categories: ,
Share this:
Description
INDUSTRIES

Typical applications

Medical Device Manufacturing
Microelectronics
Pharmaceutical

Filter Specifications

EN1822 H13 – U17
ISO 29463 ISO 35 H – ISO 75 U
Filter Depth (mm) 69
Media Type (Standard) Fibreglass
Media Type (Optional) eFRM
Frame Material Aluminium
Seperator Style Hot Melt
Gasket Material (Standard) PU Gel
Gasket Material (Optional) Silicone Gel
Gasket Position Downstream
Faceguard Position Both Sides
Antimicrobial Available No
Recommended Final Resistance 500 Pa
Max Operating Temperature 70ºC
Air Filtration Certificate UL 900, FM 4920

Housing Specifications

Housing Depth (mm) 300
Housing Material Stainless Steel
Supply Air Grille Material Stainless Steel
Supply Air Grille Type (Standard) Perforated
Supply Air Grille Type (Optional) Swirl
Inlet Collar (mm) 250, 300
Inlet Diffuser (Standard) Adjustable Distribution Plate
Inlet Diffuser (Optional) Adjustable Radial Damper
Special Size Available Yes
