AstroHood S-III RSR-III
- Visually pleasing room side design
- Leak free housing – extruded aluminium material with fully welded corners
- Available for gasket or gel seal filter
- Tool free filter and diffuser installation
- Prefixed air entry distribution plate
- Hygienic designed – no gap between diffuser and the housing
- Standard and high capacity filters are interchangeable
- Perforated or swirl diffusers available
- No centre divider – increase filter area and unrestricted airflow uniformity
- Patent pending test port providing excellent air flow uniformity
AstroHood S-III RSR-III HEPA module is room side replaceable HEPA terminal housing. It’s designed to replace HEPA filter without using any tools. Standard and high capacity filters are interchangeable without requiring any adjusting.
All New Robust Construction and Leak Free Design
AstroHood® S-III RSR-III’s robust construction and leak free feature is due to thicker construction material and continuous welding at all corners.
Designing for complicated parts has become easier, thanks to aluminium extrusion profile. AstroHood® S-III RSR-III comes with multipurpose suspension brackets that can be positioned in any point on the housing perimeter.
Supported Variety Airflow Options and Tools Free
AstroHood® S-III RSR-III can handle different volumetric of airflow with the same filter dimension, without adjusting the filter clamping devices. It is designed with tool free in mind, during new filter installation or replacement and removal of diffuser. The swirl or perforated diffuser are available in powder coated or stainless steel.
More Media Area More Airflow, ePTFE Media available
Revolution test ports designed by our R&D team help us to remove the centre divider, which means an increase in the filter area and airflow. You will save approximately 50% on energy with the new ePTFE media compared to glass fibre and this product is engineered with good chemical resistance, too.
| Housing Depth (mm) | 258 |
| Housing Material | Aluminium |
| Supply Air Grille Material (Standard) | Gi Finished with Epoxy Coated |
| Supply Air Grille Material (Optional) | Stainless Steel |
| Inlet Collar (mm) | 200, 250, 300 |
| Inlet Diffuser | Prefixed Distribution Plate |
| Top Material (Standard) | Galvalume |
| Top Material (Optional) | Aluminium, Stainless Steel |
| Special Size Available | Yes |
| Test Port | Yes |
| EN1822 | H13 – U17 |
| ISO 29463 | ISO 35 H – ISO 75 U |
| Filter Depth (mm) | 117, 128 |
| Media Type (Standard) | Fibreglass |
| Media Type (Optional) | ePTFE, eFRM |
| Frame Material | Aluminium |
| Separator Style | Hot Melt |
| Gasket Material (Standard) | PU, PU Gel |
| Gasket Material (Optional) | Neoprene, EPDM, Silicone Gel |
| Gasket Position | Upstream |
| Faceguard Position | Both Sides |
| Antimicrobial Available | Yes |
| Recommended Final Resistance | 500 Pa |
| Max Operating Temperature | 70ºC |
| UL 900 Certificate | Optional |
| FM 4920 Certificate | Optional |
